TRENCH RAMMERS - ETR03/04/05
For Compaction of Sand, Gravel, Soil & Rock Fill
The Energy Trench Rammer comes equipped with a 4 stroke Honda / Yanmar Engine for easy starting and eliminates the need for pre mixing of fuel. It features excellent balance for easy control and high compaction level compaction and Suitable for Confined Spaces Such as trenches Pipework, Back Filling and also Application’s
- Extra power for on cohesive materials & gradients.
- Extra strong, durable design.
- Engine Protection Guards
- Triple-Filtation Air Cleaner System on Petrol Models
- Duel-Filtration Fuel System.
- Efficents Shock Absorbers
Specification
| Model | Dimensions (L x W x H) mm | Shoe Size (L x W) mm | Max Output (Hp – KW) |
Fuel Type |
Fuel Tank Capacity (Ltr) | Starting Mechanism |
Operational Weight (Kg) |
Impact Force (KN) | Vibration Frequency (Hz) |
Jumping Stoke (mm) |
Percussion Rate per Min. |
|
ETR03 |
760x365x1140 |
330×285 |
3.6 / 2.7 |
Petrol |
2.8L |
Recoil |
70 |
14 |
11 |
40-85 |
450-650 |
|
ETR04 Yanmar L48 |
760x460x1140 |
330×285 |
4.8 / 3.6 |
Diesel |
2.8L |
Recoil |
80 |
14 |
10 |
40-85 |
450-650 |
|
ETR05 GX100
|
760x365x1140 |
330×285 |
3 / 2.3 |
Petrol |
2.8L |
Recoil |
70 |
14 |
11 |
40-85 |
450-650 |
