REVERSIBLE PLATE COMPACTOR-ERC3050
For aggregates, sand & cohesive materials
Heavy-duty forward & reversible compaction plate with high performance. Designed to offer maximum compaction, ideal for aggregates, sand & cohesive materials and is engineered for contracting and rental use.
- Hydraulic travel levers for positive control.
- High performance 30kN Vibration unit for maximum compaction and forward and reverse travel speed.
- Oil filled Vibrator with top quality Bearings for reliability and durability.
- Single point lifting eye
- Self-cleaning Cast Iron base plate.
- Wheel Kit fitted as standard.
Specification
| Model | Description | Engine Power | Plate Size | Static Pressure (Kg/m2) |
Centrifugal Force (kN) |
Travel Speed | Vibration Level (m/sec2) |
Weight (Kg) |
|
ERC3050DL |
ERC3050 Loncin |
6.6Hp/4.9kW | 50x69cm | 1135 | 30 | 24m/min | 90 | 185Kg |
| ERC3050DY |
ERC3050 Yanmar |
6.6Hp/4.9kW |
50x69cm |
1135 | 30 | 24m/min | 90 | 185Kg |
| ERC3050GH |
ERP350 Honda |
9.0Hp/6.7kW |
50x69cm |
1150 | 30 | 24m/min | 90 | 165Kg |
