PLATE COMPACTOR EPC95 / EPC100
For Soil, aggregates, sand & cohesive materials
Single direction, heavyweight professional compaction plate with high performance. Designed to offer maximum compaction, ideal for soil, aggregates, cohesive materials and is engineered for contracting and rental use.,
- High performance *16kN – 18kN Vibration unit for maximum compaction and forward travel speed.
- Sealed Oil filled Vibrator with top quality Bearings for reliability and durability.
- Self-cleaning Cast Iron base plate.
- *12L water tank as standard- Petrol Model only
- Wheel Kit fitted as standard.
Specification
| Model | Description | Engine Power | Plate Size | Static Pressure (Kg/m2) |
Centrifugal Force (kN) |
Travel Speed | Vibration Level (m/sec2) |
Weight (Kg) |
|
EPC95GH |
EPC95 Honda |
4.8Hp/3.5kW | 50x53cm | 442 | 16 | 26m/min | 2.45 | 100Kg |
| EPC95GL |
EPC95 LONCIN |
6.5Hp/4.8kW |
50x53cm |
442 | 16 | 26m/min | 2.45 | 100Kg |
| EPC100DL |
EPC100 LONCIN |
4.5Hp/3.4kW |
50x53cm |
547 | 18 | 26m/min | 2.45 | 110Kg |
| EPC100DY | EPC100 YANMAR L48 Diesel |
5.4Hp/4.1kW | 50x53cm | 547 | 18 | 26m/min | 2.45 | 110Kg |
