MECHANICAL POKERS & DRIVE UNITS
For Driving Mechanical Pokers
A robust and compact drive system designed for heavy site and rental use, providing effective air removal from concrete from a portable independent power source.
- 6m heavy duty reinforced flexible shaft.
- Industry standard ‘Two dog’ drive coupling.
- Robust and durable engine protection frame.
- Fitted with speed limitation to prevent over revving of engine and poker ‘burn-out’.
| Model | Part No. | Poker Diameter (mm) -(Inch) | Head Length (mm) | Shaft Length (m) | Frequency (Hz) | Amplitude (mm) | Weight (kg) |
| Mech 25mm Poker | EVP25 | 25 | 295 | 6 | 187 | 1.0 | 9.5 |
| Mech 35mm Poker | EVP35 | 35 | 330 | 6 | 187 | 1.2 | 14.5 |
| Mech 45mm Poker | EVP45 | 45 | 375 | 6 | 187 | 1.2 | 18 |
| Mech 55mm Poker | EVP55 | 55 | 390 | 6 | 187 | 1.2 | 19 |
| Mech 65mm Poker | EVP65 | 65 | 410 | 6 | 187 | 1.2 | 24 |
| Part No. | Engine model | Engine Power (Hp)-(kW) |
Engine Speed (rpm) |
Length (mm) |
Width (mm) |
Height (mm) |
Weight (kg) |
| EDU20G – Robin Petrol | EY20D | 5 – 3.7 | 2800 | 445 | 420 | 520 | 26 |
| EDU20GL – Loncin Petrol | G200F | 6.5 – 4.8 | 2800 | 445 | 420 | 520 | 26 |
| EDU20D – Kama Diesel | KM173F | 5 – 3.7 | 2800 | 500 | 430 | 630 | 38 |
| EDU20DY – Yanmar Diesel | L48 | 5.4 – 4.1 | 2800 | 500 | 430 | 630 | 42 |
| EDU20E – Electric | 230v Motor | 3.4 – 2.5 | 2800 | 450 | 240 | 300 | 14 |
