EHF POKERS
The high frequency poke vibrators (EHF) are installed in a powerful motor sealed in EPOXY resin, which protects it from the vibrations. All models are equipped with a protective system which prevents overheating. The transmission is composed of 10 metres of electric cable and 5 metres of hose reinforced with braided metal. The control panel is a waterlight (IP-52) structure constructed in polyamide with an incorporated switch.
Specification
| Part Number | Poker Diameter mm |
Length Head mm |
Hose Length m |
VPM | Amplitude | Centrifugal Force (N) |
Nominal Current (amp) | Weight (Kg) |
| EHF 38 / 5 | 38 | 360 | 5 | 13500 | 1.5 | 1500 | 5 | 12 |
| EHF 38 / 12 | 38 | 360 | 12 | 13500 | 1.5 | 1500 | 5 | 22 |
| EHF 50 / 5 | 50 | 410 | 5 | 12000 | 2.8 | 3500 | 12 | 14 |
| EHF 50 / 12 | 50 | 410 | 12 | 12000 | 2.8 | 3500 | 12 | 24 |
| EHF 60 / 5 | 60 | 416 | 5 | 12000 | 3.3 | 5500 | 18 | 16 |
| EHF 60 / 12 | 60 | 416 | 12 | 12000 | 3.3 | 5500 | 18 | 26 |
| EHF 70 / 5 | 70 | 405 | 5 | 12000 | 2.5 | 7000 | 17 | 18 |
| EHF 70 / 12 | 70 | 405 | 12 | 12000 | 2.5 | 7000 | 17 | 28 |
Other Sizes Available on Request
